High Gain UHF RFID Antenna

Product Details:
Place of Origin: China
Brand Name: MS
Certification: RoHS
Model Number: MS-868BLG-003
Payment & Shipping Terms:
Minimum Order Quantity: 10 PCS
Price: USD$ 7 / PCS - USD$ 9 / PCS
Packaging Details: 5 PCS / BOX
Delivery Time: 10-15 days
Payment Terms: D/P
Supply Ability: 10000 PCS

Detail Information

Product Name: Outdoor 868MHz Antenna Frequency: 868 ± 3 MHz
Gain: 3 DBi VSWR: < 2.0
Impedance: 50 Ohm Polarization: Linear
Radome Color: Grey / White / Black Keyword: UHF RFID Antenna
High Light:

High Gain UHF RFID Antenna


868MHz UHF RFID Antenna


Fiberglass UHF RFID Antenna

Product Description

1. Product Name:

     Outdoor 3dBi High Gain Omni-Directional 868MHz Fiberglass Antenna


2. Description:

     Low gain antennas (3 dBi) have a broad radiation pattern and are best for rugged terrain or a dense urban environment. Your signal is less likely to be blocked by obstacles such as buildings and hills tight to your location.


3. Introduction

     This 868MHz ISM Outdoor antenna is designed to a have a long distance coverage. Omni-directional high gain across all bands ensures constant reception and transmission. The UV resistant coating with fiberglass housing makes this antenna suitable to be mounted in robust outdoor environment, pole-mounting and wall- mounting bracket is included.


--3.1 Applications:

   Metering and Mesh Network

   M2M Applications

   Telemetry / Datalogging

   Remote Asset Monitoring

   868MHz Access Networks


--3.2 Features:

   N Type Female / N Type Male
   Wall Mount or Pole Mount
   Covering LoRa & ISM Band Frequencies
  RoHS compliant


4. Specs

Electrical Properties

1.1 Frequency 868 MHz
1.2 Gain (peak) 3 .2 dBi
1.3 V.S.W.R 2MAX
1.4 Return Loss -10dB Maximum
1.5 Radiation Omni-directional
1.6 Polarization Linear
1.7 Power Handling 20 W



Mechanical Properties

2.1 Cable RG-58 Coaxial Cable
2.2 Antenna Cover Fiberglass
2.3 Antenna Base Alu
2.4 Operating Temperature -20℃ ~ +65℃
2.5 Storage Temperature -30℃ ~ +75℃
2.6 Color Black or White or Grey
2.7 Connector N Male or N Female


5. Antenna Drawing

High Gain UHF RFID Antenna 0


6. Return Loss

High Gain UHF RFID Antenna 1


7. Radiation Pattern

High Gain UHF RFID Antenna 2
